Medical Research ISX-3

FAST. PRECISE. PATIENT-SAFE.

You want to use impedance spectroscopy in a medical research application? You like it simple, precise and fast and you don't want to worry about patient safety? Then check out the Medical Research ISX-3 impedance analyzer.

Configure now

It bases on our ISX-3 impedance analyzer. It is equipped with Sciospec’s IF frontend with 4-port BNC interface supporting simple 2 point measurements, as well as 3 and 4 electrode configurations. Within the measurement range from 100 mHz to 10 MHz (extendable to 40 or 100 MHz) it covers a dynamic range of 300dB (mOhm…TOhm) with a base precision of 0.01%.

Additionally the Medical Research ISX-3 includes measures for enhanced electrical safety including medical grade isolation enabling a safe operation of the instrument in medical research settings.

Publications with the Medical Research ISX-3

CHARACTERIZATION OF THE ENCAPSULATION PROCESS OF DEEP BRAIN STIMULATION ELECTRODES USING IMPEDANCE SPECTROSCOPY IN A RODENT MODEL

ISX-3 facts

Compact impedance analyzer
IF Frontend 100 mHz…10 MHz, mOhm…TOhm
Frequency extendable to 40 MHz or even 100 MHz
2, 3 and 4 electrode configurations
High resolution (up to 2048 frequencies per sweep)
Base precision of 0.01%
+/- 1 V DC Bias
ExtensionPort for application specific frontends
Ultra-fast hardware synchronization through sync in/out connectors (optional)
Simple connection through Full Speed USB, Ethernet or Wireless LAN
PC-based control & data analysis (Sciospec software suit included)
Sciospec COM-Interface for full instrument control from Java, C, Python, LabView, Matlab etc.

Medical Research ISX-3 Extras

Two 4 point channels:
- First channel AC coupled
- Multiplexed second channel DC coupled
Additional Multiplexers available
- First 4-point measurement channel DC coupled (external AC coupling interface included)
- Multiplexer: Choose between 16, 32 or 64 channels being AC coupled
Integrated battery pack for measurements up to 3 hours
IsoIO (isolated IO module)
- 12 isolated digital outputs
- 12 isolated digital inputs with pull-ups
- 4 isolated bidrectional I²C ports with pull-ups
- Isolated digital supply rail (default 3.3V)
Optimized for electrial safety

Medical Research ISX-3 with 32-channel multiplexer

In a very simple setup we used the Medical Research ISX-3 with a 32-channel MUX to measure the forearm impedance change caused movements of the hand.

Application brief
IMPEDANCE MEASUREMENT OF A FOREARM

The ISX-3 impedance analyzer is not a medical product and as such its intended purpose does not include diagnosis and/or treatment of patients. But the Medical Research ISX-3 includes several added safety measures specified in accordance with DIN EN 60601-1:2013-12 "Medical electrical equipment – Part 1: General requirements for basic safety and essential performance". These measures ease the application for excemptions for experiments on patients.

Medical grade safety features

Enclosure: prevention of contact between electrical circuitry and external equipment or humans, shielding of measurement frontend (noise reduction) and mechanical safety
Medical grade power supply: external isolated AC/DC converter supplies device with 12 V DC, additionally stand alone battery operation is possible including software controllable electromechanical switch-off for DC input lines
Isolated Full speed USB interface: fullspeed USB port for instrument control and data readout from PC
Ethernet interface: standard RJ45 Ethernet interface for remote control of the instrument
- The interface is not internally isolated. An external medical grade network isolator (included in the offer) can be inserted in the communication path to ensure safe isolation ratings.
IsoIO module: low level communication interfaces including hardware synchronisation and flexible programmable IO standards including serial (UART, SPI, I2C) for use of the instrument with other external equipment
Measurement and control modules: core functionality of the impedance analyzer including measurement control, signal processing, excitation generation and analog measurement functions
AC coupling frontend: External module for AC coupling of measurements ports. Blocks DC currents and adds a high pass filter characterisitic limiting low frequency currents. Isolates the instrument galvanically from the measurement object or patient interface.
